Duct-O-Wire Conductor Systems

8-Bar Conductor Systems - When contour cover shape is specified or requested.
.

Side Contact Figure 8 Conductor Systems - Monorails and some underhung units which require special
mounting hanger brackets to fit the manufacture’s tracks.
Not Recommended for outdoor use.
.

Totally Enclosed Figure 8 Conductor Systems - Prevents airborn Contaminants from collecting on conductor
surfaces.
.

Heated Figure 8 Conductor Systems
- To Prevent ice build-up problems such as outdoor yard cranes
or indoor frozen food storage.
.

Complete 10’ Conductor Assemblies with Heater Wire and Splice Cover for Indoor Locations
with Heating Temperatures less than 160 degrees F (Orange)

Complete Expansion Gap Assemblies with Heater Wire and Splice Cover for Indoor Locations
with Heating Temperatures less than 160 degrees F (Orange)

Complete 10’ Conductor Assemblies with Heater Wire and Splice Cover for Outdoor Locations
with Heating Temperatures less than 160 degrees F (Gray)

Complete Expansion Gap Assemblies with Heater Wire and Splice Cover for Outdoor Locations
with Heating Temperatures less than 160 degrees F (Gray)

Complete 10’ Conductor Assemblies with Heater Wire and Splice Cover for Locations with
Heating Temperatures less than 280 degrees F (Yellow)

Complete Expansion Gap Assemblies with Heater Wire and Splice Cover for Locations with
Heating Temperatures less than 280 degrees F (Yellow)

Mounting Brackets - Heated Figure 8 uses the same mounting as Figure 8

Insulated Hanger and Clamp Assemblies - Heated Figure 8 uses the same mounting as Figure 8

Power Feed Assemblies

Additional System Components

Additional Heater Wire Components

Heated Conductor Control Cabinets

* Heated conductor systems must be designed for specific heating capabilities based upon length and numer of conductors. The heating elements are calculated by the factory to produce the desired wattage output.
.
