Black BearMonorail Wire Rope
Ordering Options
Shipping cost are invoiced separately for express “add to cart” ordering.
For Visa and MasterCard orders by phone, please contact MBI.
T SeriesWithout Controls - Double Reeve - 3 Phase - 1 Speed & 2 Speeds Hoist / Trolley
Model
Cap.(Ton)
Reeving
Lift
Hoist(HP)
HoistSpeed(FPM)
TrolleySpeed(FPM)
H(in)
Flange Width (in)
Unit List Price*
TUAH-100DB-20
1
2PD
20
3
33.6
0.33
19.8
4~11.25
Contact MBI
TUAH-100DB-30
30
TUAH-100DB-40
40
TUBH-200DB-20
2
5
28.6
0.54
23.1
TUBH-200DB-30
TUBH-200DB-40
TUCH-300DB-20
7
22.1
27.4
5~13
TUCH-300DB-30
TUCH-300DB-40
TUDH-500DB-20
9
19.1
28.1
TUDH-500DB-30
TUDH-500DB-40
TUEAH-750DB-20
7.5
11
15.9
1.5
38.6
6~14
TUEAH-750DB-30
TUEAH-750DB-40
TUFAH-1000DB-20
10
15
16.1
42.7
TUFAH-1000DB-30
TUFAH-1000DB-40
TUIH-1500DB-20
3PD
17.5
14.0
57.2
TUIH-1500DB-30
TUIH-1500DB-40
Note:
1. Dimensions are approximate. If clearance is critical, ask for certified drawings.
2. All prices in U.S. Dollars F.O.B. Ontario, California, Prepaid & Add
3. Prices Subject to Change without notice.
4. Hoist is dual voltage (230/460V) motor, and the standard set up is 460V with 230V Brake Coil
5. 460 Brake Coil is also available at the same price.
6. Trolley is dual voltage (230 / 460V) motor, and standard setup is 460V with DC100V Brake Coil through rectifier.
7. STD Controls consist of Hoist & Trolley Contactors, Transformer, Terminal Block, Control Box.
8. Control Voltage is 110V. Pendent / Radio / Inverter Control are available.
9. Custom Flange Widths are available. Refer to option page.
10. Upper / Lower Geared Limited Switch & Encoder are available.
